| | mitkClassMacro (VtkPropRenderer, BaseRenderer) |
| |
| | mitkNewMacro2Param (VtkPropRenderer, const char *, vtkRenderWindow *) |
| |
| void | SetPropertyKeys (vtkInformation *info) |
| | Store and propagate vtkInformation during rendering. More...
|
| |
| int | Render (RenderType type) |
| | Render the scene for the given render type. More...
|
| |
| virtual void | PrepareRender () |
| | Perform all preparations necessary before a VTK Render() call. More...
|
| |
| virtual void | MakeCurrent () |
| | Make the current render window the active OpenGL context. More...
|
| |
| void | SetDataStorage (mitk::DataStorage *storage) override |
| | Set the data storage that will be used for rendering. More...
|
| |
| void | InitRenderer (vtkRenderWindow *renderwindow) override |
| | Initialize the renderer with the given VTK render window. More...
|
| |
| virtual void | Update (mitk::DataNode *datatreenode) |
| | Update a specific data node in the rendering pipeline. More...
|
| |
| void | SetMapperID (const MapperSlotId mapperId) override |
| | Set the mapper slot ID to select 2D or 3D mappers. More...
|
| |
| void | InitSize (int w, int h) override |
| | Initialize the renderer size. More...
|
| |
| void | Resize (int w, int h) override |
| | Resize the renderer. More...
|
| |
| | itkSetEnumMacro (PickingMode, PickingMode) |
| | Set the picking mode. This method is used to set the picking mode for 3D object picking. The user can select one of the three options WorldPointPicking, PointPicking and CellPicking. The first option uses the zBuffer from graphics rendering, the second uses the 3D points from the closest surface mesh, and the third option uses the cells of that mesh. The last option is the slowest, the first one the fastest. However, the first option cannot use transparent data object and the tolerance of the picked position to the selected point should be considered. PointPicking also need a tolerance around the picking position to select the closest point in the mesh. The CellPicker performs very well, if the foreground surface part (i.e. the surfacepart that is closest to the scene's cameras) needs to be picked. More...
|
| |
| | itkGetEnumMacro (PickingMode, PickingMode) |
| |
| void | PickWorldPoint (const Point2D &displayPoint, Point3D &worldPoint) const override |
| | Pick a world point from a display position using the current picking mode. More...
|
| |
| mitk::DataNode * | PickObject (const Point2D &displayPosition, Point3D &worldPosition) const override |
| | Pick the data node at the given display position. More...
|
| |
| bool | SetWorldGeometryToDataStorageBounds () override |
| |
| void | InitPathTraversal () |
| | Used by vtkPointPicker/vtkPicker. This will query a list of all objects in MITK and provide every vtk based mapper to the picker. More...
|
| |
| vtkAssemblyPath * | GetNextPath () |
| | Used by vtkPointPicker/vtkPicker. This will query a list of all objects in MITK and provide every vtk based mapper to the picker. More...
|
| |
| int | GetNumberOfPaths () |
| | Return the number of assembly paths in the current traversal. More...
|
| |
| const vtkWorldPointPicker * | GetWorldPointPicker () const |
| | Return the world point picker. More...
|
| |
| const vtkPointPicker * | GetPointPicker () const |
| | Return the point picker. More...
|
| |
| const vtkCellPicker * | GetCellPicker () const |
| | Return the cell picker. More...
|
| |
| virtual void | ReleaseGraphicsResources (vtkWindow *renWin) |
| | Release VTK-based graphics resources. More...
|
| |
| MappersMapType | GetMappersMap () const |
| | Return the current map of mappers sorted by layer. More...
|
| |
| | mitkClassMacroItkParent (BaseRenderer, itk::Object) |
| |
| | BaseRenderer (const char *name=nullptr, vtkRenderWindow *renderWindow=nullptr) |
| | Construct a BaseRenderer with an optional name and vtkRenderWindow. More...
|
| |
| void | RemoveAllLocalStorages () |
| | Remove all registered local storages and notify observers via RendererResetEvent. More...
|
| |
| void | RegisterLocalStorageHandler (BaseLocalStorageHandler *lsh) |
| | Register a local storage handler with this renderer. More...
|
| |
| void | UnregisterLocalStorageHandler (BaseLocalStorageHandler *lsh) |
| | Unregister a previously registered local storage handler. More...
|
| |
| virtual DataStorage::Pointer | GetDataStorage () const |
| | Get the DataStorage used by this renderer. More...
|
| |
| vtkRenderWindow * | GetRenderWindow () const |
| | Get the vtkRenderWindow associated with this renderer. More...
|
| |
| vtkRenderer * | GetVtkRenderer () const |
| | Get the underlying vtkRenderer used for VTK rendering. More...
|
| |
| Dispatcher::Pointer | GetDispatcher () const |
| | Get the dispatcher, which handles events for this base renderer. More...
|
| |
| virtual void | DrawOverlayMouse (Point2D &) |
| | Draw an overlay mouse cursor at the given position. More...
|
| |
| virtual void | SetWorldTimeGeometry (const TimeGeometry *geometry) |
| | Set the world time geometry using the given TimeGeometry. More...
|
| |
| virtual const TimeGeometry * | GetWorldTimeGeometry () |
| |
| virtual void | SetInteractionReferenceGeometry (const TimeGeometry *geometry) |
| | Set the interaction reference world time geometry using the given TimeGeometry. More...
|
| |
| virtual const TimeGeometry * | GetInteractionReferenceGeometry () |
| | Get the current interaction reference geometry. More...
|
| |
| virtual bool | GetReferenceGeometryAligned () |
| | Return if the reference geometry aligns with the base renderer's world geometry. If true, the interaction reference geometry aligns with the base renderer's current world geometry. False otherwise. More...
|
| |
| virtual const BaseGeometry * | GetCurrentWorldGeometry () |
| | Get the current time-extracted 3D-geometry. More...
|
| |
| virtual const PlaneGeometry * | GetCurrentWorldPlaneGeometry () |
| | Get the current slice-extracted 2D-geometry. More...
|
| |
| virtual void | SetSlice (unsigned int slice) |
| | Set the slice that should be used for geometry extraction. More...
|
| |
| virtual unsigned int | GetSlice () const |
| |
| virtual void | SetTimeStep (unsigned int timeStep) |
| | Set the timestep that should be used for geometry extraction. More...
|
| |
| virtual unsigned int | GetTimeStep () const |
| |
| TimeStepType | GetTimeStep (const BaseData *data) const |
| | Get the timestep of a BaseData object which exists at the time of the currently displayed content. More...
|
| |
| ScalarType | GetTime () const |
| | Get the time in ms of the currently display content (geometry). More...
|
| |
| virtual void | SetGeometry (const itk::EventObject &geometrySliceEvent) |
| | Set the world time geometry using the geometry of the given event. More...
|
| |
| virtual void | UpdateGeometry (const itk::EventObject &geometrySliceEvent) |
| | Set the current world plane geometry using the existing current world geometry. More...
|
| |
| virtual void | SetGeometrySlice (const itk::EventObject &geometrySliceEvent) |
| | Set the current slice using "SetSlice" and update the current world geometry and the current world plane geometry. More...
|
| |
| virtual void | SetGeometryTime (const itk::EventObject &geometryTimeEvent) |
| | Set the current time using "SetTimeStep" and update the current world geometry and the current world plane geometry. More...
|
| |
| virtual DataNode * | GetCurrentWorldPlaneGeometryNode () |
| |
| void | SendUpdateSlice () |
| | Modify the update time of the current world plane geometry and force reslicing. More...
|
| |
| virtual unsigned long | GetCurrentWorldPlaneGeometryUpdateTime () |
| | Get timestamp of the update time of the current world plane geometry. More...
|
| |
| virtual unsigned long | GetTimeStepUpdateTime () |
| | Get timestamp of the update time of the current timestep. More...
|
| |
| virtual MapperSlotId | GetMapperID () |
| | Get the currently used mapperID. More...
|
| |
| virtual MapperSlotId | GetMapperID () const |
| |
| virtual int * | GetSize () const |
| | Get the size of the render window in pixels. More...
|
| |
| virtual int * | GetViewportSize () const |
| | Get the size of the VTK viewport in pixels. More...
|
| |
| void | SetSliceNavigationController (SliceNavigationController *SlicenavigationController) |
| | Replace the current SliceNavigationController. More...
|
| |
| virtual CameraController * | GetCameraController () |
| | Get the CameraController for this renderer. More...
|
| |
| virtual SliceNavigationController * | GetSliceNavigationController () |
| | Get the SliceNavigationController for this renderer. More...
|
| |
| virtual CameraRotationController * | GetCameraRotationController () |
| | Get the CameraRotationController for this renderer. More...
|
| |
| virtual bool | GetEmptyWorldGeometry () |
| | Return whether the current world geometry is empty (has zero extent). More...
|
| |
| virtual bool | GetKeepDisplayedRegion () |
| | Getter/Setter for defining if the displayed region should be shifted or rescaled if the render window is resized. More...
|
| |
| virtual void | SetKeepDisplayedRegion (bool _arg) |
| |
| const char * | GetName () const |
| | Return the name of the base renderer. More...
|
| |
| int | GetSizeX () const |
| | Return the size in x-direction of the base renderer. More...
|
| |
| int | GetSizeY () const |
| | Return the size in y-direction of the base renderer. More...
|
| |
| const double * | GetBounds () const |
| | Return the bounds of the bounding box of the current world geometry (time-extracted 3D-geometry). More...
|
| |
| void | RequestUpdate () |
| | Request an asynchronous rendering update for this render window via the RenderingManager. More...
|
| |
| void | ForceImmediateUpdate () |
| | Force an immediate synchronous rendering update for this render window. More...
|
| |
| unsigned int | GetNumberOfVisibleLODEnabledMappers () const |
| | Return the number of mappers which are visible and have level-of-detail rendering enabled. More...
|
| |
| void | DisplayToWorld (const Point2D &displayPoint, Point3D &worldIndex) const |
| | Convert a display point to a 3D world coordinate. More...
|
| |
| void | DisplayToPlane (const Point2D &displayPoint, Point2D &planePointInMM) const |
| | Convert a display point to a 2D plane coordinate in millimeters. More...
|
| |
| void | WorldToDisplay (const Point3D &worldIndex, Point2D &displayPoint) const |
| | Convert a 3D world coordinate to a 2D display point. More...
|
| |
| void | WorldToView (const Point3D &worldIndex, Point2D &viewPoint) const |
| | Convert a 3D world coordinate to a 2D viewport point. More...
|
| |
| void | PlaneToDisplay (const Point2D &planePointInMM, Point2D &displayPoint) const |
| | Convert a 2D plane coordinate in millimeters to a 2D display point. More...
|
| |
| void | PlaneToView (const Point2D &planePointInMM, Point2D &viewPoint) const |
| | Convert a 2D plane coordinate in millimeters to a 2D viewport point. More...
|
| |
| double | GetScaleFactorMMPerDisplayUnit () const |
| | Get the scale factor relating millimeters to display pixels. More...
|
| |
| Point2D | GetDisplaySizeInMM () const |
| | Get the size of the render window in millimeters. More...
|
| |
| Point2D | GetViewportSizeInMM () const |
| | Get the size of the VTK viewport in millimeters. More...
|
| |
| Point2D | GetOriginInMM () const |
| | Get the origin of the viewport in plane coordinates (millimeters). More...
|
| |
| virtual bool | GetConstrainZoomingAndPanning () const |
| | Get whether zooming and panning are constrained to the displayed geometry. More...
|
| |
| virtual void | SetConstrainZoomingAndPanning (bool constrain) |
| | Enable or disable constraining of zooming and panning. More...
|
| |
Organizes the MITK rendering process within the VTK rendering pipeline.
The MITK rendering process is completely integrated into the VTK rendering pipeline. vtkMitkRenderProp is a custom vtkProp derived class that implements the rendering interface between MITK and VTK. It redirects render() calls to VtkPropRenderer, which is responsible for rendering the data tree nodes.
VtkPropRenderer replaces the old OpenGLRenderer.
Definition at line 50 of file mitkVtkPropRenderer.h.
Public Types inherited from mitk::BaseRenderer
