Represents a keyboard interaction event. More...

#include <mitkInteractionKeyEvent.h>

Inheritance diagram for mitk::InteractionKeyEvent:

Collaboration diagram for mitk::InteractionKeyEvent:

[legend]

Public Member Functions
	mitkClassMacro (InteractionKeyEvent, InteractionEvent) mitkNewMacro3Param(Self

bool	IsSuperClassOf (const InteractionEvent::Pointer &baseClass) const override
	Check if the provided event is an InteractionKeyEvent or derived. More...

ModifierKeys	GetModifiers () const
	Get the modifier keys held during this key event. More...

std::string	GetKey () const
	Get the key that was pressed. More...

Public Member Functions inherited from mitk::InteractionEvent
	mitkClassMacroItkParent (InteractionEvent, itk::LightObject)

	mitkNewMacro1Param (Self, BaseRenderer *)

void	SetSender (BaseRenderer *sender)
	Set the BaseRenderer that sent this event. More...

BaseRenderer *	GetSender () const
	Get the BaseRenderer that sent this event. More...

Public Attributes
BaseRenderer const std::string	ModifierKeys

Protected Member Functions
	InteractionKeyEvent (BaseRenderer *, const std::string &key, ModifierKeys modifiers)

	~InteractionKeyEvent () override

bool	IsEqual (const InteractionEvent &) const override

Protected Member Functions inherited from mitk::InteractionEvent
	InteractionEvent (BaseRenderer *)

	~InteractionEvent () override

Additional Inherited Members
Public Types inherited from mitk::InteractionEvent
enum	MouseButtons { NoButton , LeftMouseButton , RightMouseButton , MiddleMouseButton }
	Enumeration of mouse button states. More...

enum	ModifierKeys { NoKey , ShiftKey , ControlKey , AltKey }
	Enumeration of keyboard modifier keys. More...

Static Public Attributes inherited from mitk::InteractionEvent
static const std::string	KeyEsc
	String constants for special keys used in key events and state machine patterns. More...

static const std::string	KeyEnter
	"Enter" key constant. More...

static const std::string	KeyReturn
	"Return" key constant. More...

static const std::string	KeyDelete
	"Delete" key constant. More...

static const std::string	KeyArrowUp
	"ArrowUp" key constant. More...

static const std::string	KeyArrowDown
	"ArrowDown" key constant. More...

static const std::string	KeyArrowLeft
	"ArrowLeft" key constant. More...

static const std::string	KeyArrowRight
	"ArrowRight" key constant. More...

static const std::string	KeyF1
	"F1" key constant. More...

static const std::string	KeyF2
	"F2" key constant. More...

static const std::string	KeyF3
	"F3" key constant. More...

static const std::string	KeyF4
	"F4" key constant. More...

static const std::string	KeyF5
	"F5" key constant. More...

static const std::string	KeyF6
	"F6" key constant. More...

static const std::string	KeyF7
	"F7" key constant. More...

static const std::string	KeyF8
	"F8" key constant. More...

static const std::string	KeyF9
	"F9" key constant. More...

static const std::string	KeyF10
	"F10" key constant. More...

static const std::string	KeyF11
	"F11" key constant. More...

static const std::string	KeyF12
	"F12" key constant. More...

static const std::string	KeyPos1
	"Pos1" (Home) key constant. More...

static const std::string	KeyEnd
	"End" key constant. More...

static const std::string	KeyInsert
	"Insert" key constant. More...

static const std::string	KeyPageUp
	"PageUp" key constant. More...

static const std::string	KeyPageDown
	"PageDown" key constant. More...

static const std::string	KeySpace
	"Space" key constant. More...

Detailed Description

Represents a keyboard interaction event.

Stores the pressed key (as a string, including special key constants from InteractionEvent) and the modifier keys held during the event. Two InteractionKeyEvents are considered equal if they have the same key and the same modifiers.

See also: InteractionEvent; InteractionPositionEvent

Definition at line 44 of file mitkInteractionKeyEvent.h.

Constructor & Destructor Documentation

◆ InteractionKeyEvent()

mitk::InteractionKeyEvent::InteractionKeyEvent	(	BaseRenderer *	,
		const std::string &	key,
		ModifierKeys	modifiers
	)

protected

◆ ~InteractionKeyEvent()

mitk::InteractionKeyEvent::~InteractionKeyEvent ( )

overrideprotected

Member Function Documentation

◆ GetKey()

std::string mitk::InteractionKeyEvent::GetKey ( ) const

Get the key that was pressed.

Returns: The key as a string. For special keys, this matches the KeyXxx constants.

◆ GetModifiers()

ModifierKeys mitk::InteractionKeyEvent::GetModifiers ( ) const

Get the modifier keys held during this key event.

Returns: The modifier keys as a ModifierKeys bitmask.

◆ IsEqual()

bool mitk::InteractionKeyEvent::IsEqual ( const InteractionEvent & ) const

overrideprotectedvirtual

Reimplemented from mitk::InteractionEvent.

◆ IsSuperClassOf()

bool mitk::InteractionKeyEvent::IsSuperClassOf ( const InteractionEvent::Pointer & baseClass ) const

overridevirtual

Check if the provided event is an InteractionKeyEvent or derived.

Parameters

[in] baseClass The event to check.

Returns: true if baseClass is an InteractionKeyEvent or derived from it.

Reimplemented from mitk::InteractionEvent.

◆ mitkClassMacro()

mitk::InteractionKeyEvent::mitkClassMacro	(	InteractionKeyEvent	,
		InteractionEvent
	)

Member Data Documentation

◆ ModifierKeys

BaseRenderer const std::string mitk::InteractionKeyEvent::ModifierKeys

Definition at line 48 of file mitkInteractionKeyEvent.h.

The documentation for this class was generated from the following file:

mitkInteractionKeyEvent.h
