Property for storing RGB color values. More...

#include <mitkColorProperty.h>

Inheritance diagram for mitk::ColorProperty:

Collaboration diagram for mitk::ColorProperty:

[legend]

Public Types
typedef mitk::Color	ValueType
	The type of the value stored by this property. More...

Public Member Functions
	mitkClassMacro (ColorProperty, BaseProperty)

Pointer	Clone () const

	mitkNewMacro1Param (ColorProperty, const float *)

	mitkNewMacro1Param (ColorProperty, const mitk::Color &)

	mitkNewMacro3Param (ColorProperty, const float, const float, const float)

const mitk::Color &	GetColor () const
	Get the color value. More...

const mitk::Color &	GetValue () const
	Get the color value (alias for GetColor()). More...

std::string	GetValueAsString () const override
	Return the color as a human-readable string. More...

void	SetColor (const mitk::Color &color)
	Set the color value. More...

void	SetValue (const mitk::Color &color)
	Set the color value (alias for SetColor()). More...

void	SetColor (float red, float green, float blue)
	Set the color from individual RGB components. More...

bool	ToJSON (nlohmann::json &j) const override
	Serialize the color to JSON as a three-element array [r, g, b]. More...

bool	FromJSON (const nlohmann::json &j) override
	Deserialize the color from a JSON three-element array [r, g, b]. More...

BaseProperty &	operator= (const BaseProperty &property)
	Assign a property value to this instance. More...

Public Member Functions inherited from mitk::BaseProperty
	mitkClassMacroItkParent (BaseProperty, itk::Object)

Pointer	Clone () const

bool	operator== (const BaseProperty &property) const
	Compare two properties for equality. More...

BaseProperty &	operator= (const BaseProperty &property)
	Assign a property value to this instance. More...

bool	AssignProperty (const BaseProperty &property)
	Assign a property value to this instance and report success. More...

Static Public Member Functions
static Pointer	New ()

Protected Member Functions
	ColorProperty ()

	ColorProperty (const ColorProperty &other)

	ColorProperty (const float red, const float green, const float blue)

	ColorProperty (const float color[3])

	ColorProperty (const mitk::Color &color)

	mitkCloneMacro (ColorProperty)

Protected Member Functions inherited from mitk::BaseProperty
	BaseProperty ()

	BaseProperty (const BaseProperty &other)

	~BaseProperty () override

Protected Attributes
mitk::Color	m_Color

Additional Inherited Members
Static Public Attributes inherited from mitk::BaseProperty
static const std::string	VALUE_CANNOT_BE_CONVERTED_TO_STRING
	Default return value for properties that cannot be converted to a string. More...

Detailed Description

Property for storing RGB color values.

Stores an RGB color with float precision (each component 0.0f to 1.0f). Used to associate a rendering color with a DataNode.

Note: If you want to apply the mitk::ColorProperty to an mitk::Image, make sure to set the mitk::RenderingModeProperty to a mode which supports color (e.g. LOOKUPTABLE_LEVELWINDOW_COLOR). For an example, see mitkImageVtkMapper2DColorTest.cpp in Core/Code/Rendering.

See also: BaseProperty; RenderingModeProperty

Definition at line 61 of file mitkColorProperty.h.

Member Typedef Documentation

◆ ValueType

typedef mitk::Color mitk::ColorProperty::ValueType

The type of the value stored by this property.

Definition at line 86 of file mitkColorProperty.h.

Constructor & Destructor Documentation

◆ ColorProperty() [1/5]

mitk::ColorProperty::ColorProperty ( )

protected

◆ ColorProperty() [2/5]

mitk::ColorProperty::ColorProperty ( const ColorProperty & other )

protected

◆ ColorProperty() [3/5]

mitk::ColorProperty::ColorProperty	(	const float	red,
		const float	green,
		const float	blue
	)

protected

◆ ColorProperty() [4/5]

mitk::ColorProperty::ColorProperty ( const float color[3] )

protected

◆ ColorProperty() [5/5]

mitk::ColorProperty::ColorProperty ( const mitk::Color & color )

protected

Member Function Documentation

◆ Clone()

Pointer mitk::ColorProperty::Clone ( ) const

◆ FromJSON()

bool mitk::ColorProperty::FromJSON ( const nlohmann::json & j )

overridevirtual

Deserialize the color from a JSON three-element array [r, g, b].

Parameters

[in] j The JSON array containing the RGB values.

Returns: Always true.

Implements mitk::BaseProperty.

◆ GetColor()

const mitk::Color& mitk::ColorProperty::GetColor ( ) const

Get the color value.

Returns: A const reference to the stored color.

◆ GetValue()

const mitk::Color& mitk::ColorProperty::GetValue ( ) const

Get the color value (alias for GetColor()).

Returns: A const reference to the stored color.

◆ GetValueAsString()

std::string mitk::ColorProperty::GetValueAsString ( ) const

overridevirtual

Return the color as a human-readable string.

Returns: A string representation of the RGB values.

Reimplemented from mitk::BaseProperty.

◆ mitkClassMacro()

mitk::ColorProperty::mitkClassMacro	(	ColorProperty	,
		BaseProperty
	)

◆ mitkCloneMacro()

mitk::ColorProperty::mitkCloneMacro ( ColorProperty )

protected

◆ mitkNewMacro1Param() [1/2]

mitk::ColorProperty::mitkNewMacro1Param	(	ColorProperty	,
		const float *
	)

◆ mitkNewMacro1Param() [2/2]

mitk::ColorProperty::mitkNewMacro1Param	(	ColorProperty	,
		const mitk::Color &
	)

◆ mitkNewMacro3Param()

mitk::ColorProperty::mitkNewMacro3Param	(	ColorProperty	,
		const float	,
		const float	,
		const float
	)

◆ New()

static Pointer mitk::ColorProperty::New ( )

static

Referenced by mitk::python::dictToProperty(), pythonValueToProperty(), and pythonValueToPropertyWithType().

◆ operator=()

BaseProperty& mitk::BaseProperty::operator=

Assign a property value to this instance.

Performs a polymorphic assignment from the given property. The assignment succeeds only if the source and target properties are of the same type. The subclass-specific Assign() method is called to perform the actual value copy.

Subclasses must implement Assign(const BaseProperty&) and call the superclass Assign method for proper handling. The copy assignment operator of the subclass should be disabled and the base class operator should be made visible using "using" statements.

Parameters

[in] property The property whose value should be assigned to this instance.

Returns: A reference to this property.

See also: AssignProperty; Assign

◆ SetColor() [1/2]

void mitk::ColorProperty::SetColor ( const mitk::Color & color )

Set the color value.

Marks the property as modified if the new color differs from the current one.

Parameters

[in] color The new color to set.

◆ SetColor() [2/2]

void mitk::ColorProperty::SetColor	(	float	red,
		float	green,
		float	blue
	)

Set the color from individual RGB components.

Parameters

[in]	red	Red component (0.0f to 1.0f).
[in]	green	Green component (0.0f to 1.0f).
[in]	blue	Blue component (0.0f to 1.0f).

◆ SetValue()

void mitk::ColorProperty::SetValue ( const mitk::Color & color )

Set the color value (alias for SetColor()).

Parameters

[in] color The new color to set.

◆ ToJSON()

bool mitk::ColorProperty::ToJSON ( nlohmann::json & j ) const

overridevirtual

Serialize the color to JSON as a three-element array [r, g, b].

Parameters

[out] j The JSON object to write the value into.

Returns: Always true.

Implements mitk::BaseProperty.

Member Data Documentation

◆ m_Color

mitk::Color mitk::ColorProperty::m_Color

protected

Definition at line 64 of file mitkColorProperty.h.

The documentation for this class was generated from the following file:

mitkColorProperty.h
