GUI for slices interpolation. More...

#include <QmitkSlicesInterpolator.h>

Inheritance diagram for QmitkSlicesInterpolator:

Collaboration diagram for QmitkSlicesInterpolator:

[legend]

Public Slots
virtual void	setEnabled (bool)

void	EnableInterpolation (bool)

void	Enable3DInterpolation (bool)
	Enables or disables 3D surface interpolation. More...

void	FinishInterpolation (mitk::SliceNavigationController *slicer=nullptr)

Signals
void	SignalRememberContourPositions (bool)

void	SignalShowMarkerNodes (bool)

Public Member Functions
	QmitkSlicesInterpolator (QWidget parent=nullptr, const char name=nullptr)

void	Initialize (mitk::ToolManager toolManager, const QList< QmitkRenderWindow > &windows)

void	Uninitialize ()
	Releases resources and disconnects from the tool manager and render windows. More...

	~QmitkSlicesInterpolator () override

void	SetDataStorage (mitk::DataStorage::Pointer storage)
	Sets the data storage used for interpolation feedback nodes. More...

mitk::DataStorage *	GetDataStorage ()
	Returns the current data storage. More...

void	SetActiveLabelValue (mitk::MultiLabelSegmentation::LabelValueType labelValue)
	Sets the active label value for which interpolation is performed. More...

void	OnToolManagerWorkingDataModified ()

void	OnToolManagerReferenceDataModified ()

void	OnTimeChanged (itk::Object *sender, const itk::EventObject &)
	Reacts to the time changed event. Public for itk::Command callbacks. More...

void	OnSliceChanged (itk::Object *sender, const itk::EventObject &)
	Reacts to the slice changed event. Public for itk::Command callbacks. More...

void	OnSliceNavigationControllerDeleted (const itk::Object *sender, const itk::EventObject &)
	Handles deletion of a SliceNavigationController. Public for itk::Command callbacks. More...

void	OnInterpolationInfoChanged (const itk::EventObject &)

void	OnInterpolationAborted (const itk::EventObject &)

void	OnSurfaceInterpolationInfoChanged (const itk::EventObject &)

Protected Types
typedef std::map< QAction , mitk::SliceNavigationController >	ActionToSliceDimensionMapType

Protected Slots
void	OnAcceptInterpolationClicked ()

void	OnAcceptAllInterpolationsClicked ()

void	OnAccept3DInterpolationClicked ()

void	OnReinit3DInterpolation ()
	Reinitializes 3D interpolation by re-reading the plane geometries of the segmentation image. More...

void	OnAcceptAllPopupActivated (QAction *action)

void	OnInterpolationActivated (bool)

void	On3DInterpolationActivated (bool)
	Called when 3D interpolation is activated or deactivated. More...

void	OnInterpolationMethodChanged (int index)
	Called when the interpolation method combo box selection changes. More...

void	On2DInterpolationEnabled (bool)
	Called when the 2D interpolation radio button is toggled. More...

void	On3DInterpolationEnabled (bool)
	Called when the 3D interpolation radio button is toggled. More...

void	OnInterpolationDisabled (bool)
	Called when the "no interpolation" radio button is toggled. More...

void	OnShowMarkers (bool)
	Called when the "show position markers" checkbox is toggled. More...

void	Run3DInterpolation ()
	Triggers 3D surface interpolation in a background thread. More...

void	OnSurfaceInterpolationFinished ()
	Called when the surface interpolation thread completes. More...

void	StartUpdateInterpolationTimer ()
	Starts the timer that periodically triggers interpolation updates. More...

void	StopUpdateInterpolationTimer ()
	Stops the interpolation update timer. More...

void	ChangeSurfaceColor ()
	Updates the surface color to match the active label color. More...

Protected Member Functions
const ActionToSliceDimensionMapType	CreateActionToSlicer (const QList< QmitkRenderWindow * > &windows)

void	AcceptAllInterpolations (mitk::SliceNavigationController *slicer)

void	AcceptAllInterpolationsWithErrorHandling (mitk::SliceNavigationController *slicer)

bool	TranslateAndInterpolateChangedSlice (const itk::EventObject &e, mitk::SliceNavigationController *sliceNavigationController)

bool	TranslateAndInterpolateChangedSlice (const mitk::TimeGeometry *timeGeometry)

void	Interpolate (mitk::PlaneGeometry *plane)

void	UpdateVisibleSuggestion ()

void	SetCurrentContourListID ()

Protected Attributes
ActionToSliceDimensionMapType	m_ActionToSlicerMap

Detailed Description

GUI for slices interpolation.

See also: QmitkInteractiveSegmentation; mitk::SegmentationInterpolation

While mitk::SegmentationInterpolation does the bookkeeping of interpolation (keeping track of which slices contain how much segmentation) and the algorithmic work, QmitkSlicesInterpolator is responsible to watch the GUI, to notice, which slice is currently visible. It triggers generation of interpolation suggestions and also triggers acception of suggestions.

Definition at line 65 of file QmitkSlicesInterpolator.h.

Member Typedef Documentation

◆ ActionToSliceDimensionMapType

typedef std::map<QAction*, mitk::SliceNavigationController*> QmitkSlicesInterpolator::ActionToSliceDimensionMapType

protected

Definition at line 223 of file QmitkSlicesInterpolator.h.

Constructor & Destructor Documentation

◆ QmitkSlicesInterpolator()

QmitkSlicesInterpolator::QmitkSlicesInterpolator	(	QWidget *	parent = `nullptr`,
		const char *	name = `nullptr`
	)

◆ ~QmitkSlicesInterpolator()

QmitkSlicesInterpolator::~QmitkSlicesInterpolator ( )

override

Member Function Documentation

◆ AcceptAllInterpolations()

void QmitkSlicesInterpolator::AcceptAllInterpolations ( mitk::SliceNavigationController * slicer )

protected

◆ AcceptAllInterpolationsWithErrorHandling()

void QmitkSlicesInterpolator::AcceptAllInterpolationsWithErrorHandling ( mitk::SliceNavigationController * slicer )

protected

Calls AcceptAllInterpolations and reports a failure to the user in an error dialog instead of letting the exception escape into the Qt event loop.

◆ ChangeSurfaceColor

void QmitkSlicesInterpolator::ChangeSurfaceColor ( )

protectedslot

Updates the surface color to match the active label color.

◆ CreateActionToSlicer()

const ActionToSliceDimensionMapType QmitkSlicesInterpolator::CreateActionToSlicer ( const QList< QmitkRenderWindow * > & windows )

protected

◆ Enable3DInterpolation

void QmitkSlicesInterpolator::Enable3DInterpolation ( bool )

slot

Enables or disables 3D surface interpolation.

◆ EnableInterpolation

void QmitkSlicesInterpolator::EnableInterpolation ( bool )

slot

Call this from the outside to enable/disable interpolation

◆ FinishInterpolation

void QmitkSlicesInterpolator::FinishInterpolation ( mitk::SliceNavigationController * slicer = nullptr )

slot

Call this from the outside to accept all interpolations

◆ GetDataStorage()

mitk::DataStorage* QmitkSlicesInterpolator::GetDataStorage ( )

Returns the current data storage.

◆ Initialize()

void QmitkSlicesInterpolator::Initialize	(	mitk::ToolManager *	toolManager,
		const QList< QmitkRenderWindow * > &	windows
	)

To be called once before real use.

◆ Interpolate()

void QmitkSlicesInterpolator::Interpolate ( mitk::PlaneGeometry * plane )

protected

Given a PlaneGeometry, this method figures out which slice of the first working image (of the associated ToolManager) should be interpolated. The actual work is then done by our SegmentationInterpolation object.

◆ On2DInterpolationEnabled

void QmitkSlicesInterpolator::On2DInterpolationEnabled ( bool )

protectedslot

Called when the 2D interpolation radio button is toggled.

◆ On3DInterpolationActivated

void QmitkSlicesInterpolator::On3DInterpolationActivated ( bool )

protectedslot

Called when 3D interpolation is activated or deactivated.

◆ On3DInterpolationEnabled

void QmitkSlicesInterpolator::On3DInterpolationEnabled ( bool )

protectedslot

Called when the 3D interpolation radio button is toggled.

◆ OnAccept3DInterpolationClicked

void QmitkSlicesInterpolator::OnAccept3DInterpolationClicked ( )

protectedslot

◆ OnAcceptAllInterpolationsClicked

void QmitkSlicesInterpolator::OnAcceptAllInterpolationsClicked ( )

protectedslot

◆ OnAcceptAllPopupActivated

void QmitkSlicesInterpolator::OnAcceptAllPopupActivated ( QAction * action )

protectedslot

◆ OnAcceptInterpolationClicked

void QmitkSlicesInterpolator::OnAcceptInterpolationClicked ( )

protectedslot

Reaction to button clicks.

◆ OnInterpolationAborted()

void QmitkSlicesInterpolator::OnInterpolationAborted ( const itk::EventObject & )

Just public because it is called by itk::Commands. You should not need to call this.

◆ OnInterpolationActivated

void QmitkSlicesInterpolator::OnInterpolationActivated ( bool )

protectedslot

Called on activation/deactivation

◆ OnInterpolationDisabled

void QmitkSlicesInterpolator::OnInterpolationDisabled ( bool )

protectedslot

Called when the "no interpolation" radio button is toggled.

◆ OnInterpolationInfoChanged()

void QmitkSlicesInterpolator::OnInterpolationInfoChanged ( const itk::EventObject & )

Just public because it is called by itk::Commands. You should not need to call this.

◆ OnInterpolationMethodChanged

void QmitkSlicesInterpolator::OnInterpolationMethodChanged ( int index )

protectedslot

Called when the interpolation method combo box selection changes.

◆ OnReinit3DInterpolation

void QmitkSlicesInterpolator::OnReinit3DInterpolation ( )

protectedslot

Reinitializes 3D interpolation by re-reading the plane geometries of the segmentation image.

◆ OnShowMarkers

void QmitkSlicesInterpolator::OnShowMarkers ( bool )

protectedslot

Called when the "show position markers" checkbox is toggled.

◆ OnSliceChanged()

void QmitkSlicesInterpolator::OnSliceChanged	(	itk::Object *	sender,
		const itk::EventObject &
	)

Reacts to the slice changed event. Public for itk::Command callbacks.

◆ OnSliceNavigationControllerDeleted()

void QmitkSlicesInterpolator::OnSliceNavigationControllerDeleted	(	const itk::Object *	sender,
		const itk::EventObject &
	)

Handles deletion of a SliceNavigationController. Public for itk::Command callbacks.

◆ OnSurfaceInterpolationFinished

void QmitkSlicesInterpolator::OnSurfaceInterpolationFinished ( )

protectedslot

Called when the surface interpolation thread completes.

Retrieves the interpolated surface data, renders it in the active color label, and stores the surface information in the feedback node.

◆ OnSurfaceInterpolationInfoChanged()

void QmitkSlicesInterpolator::OnSurfaceInterpolationInfoChanged ( const itk::EventObject & )

Just public because it is called by itk::Commands. You should not need to call this.

◆ OnTimeChanged()

void QmitkSlicesInterpolator::OnTimeChanged	(	itk::Object *	sender,
		const itk::EventObject &
	)

Reacts to the time changed event. Public for itk::Command callbacks.

◆ OnToolManagerReferenceDataModified()

void QmitkSlicesInterpolator::OnToolManagerReferenceDataModified ( )

Just public because it is called by itk::Commands. You should not need to call this.

◆ OnToolManagerWorkingDataModified()

void QmitkSlicesInterpolator::OnToolManagerWorkingDataModified ( )

Just public because it is called by itk::Commands. You should not need to call this.

◆ Run3DInterpolation

void QmitkSlicesInterpolator::Run3DInterpolation ( )

protectedslot

Triggers 3D surface interpolation in a background thread.

◆ SetActiveLabelValue()

void QmitkSlicesInterpolator::SetActiveLabelValue ( mitk::MultiLabelSegmentation::LabelValueType labelValue )

Sets the active label value for which interpolation is performed.

◆ SetCurrentContourListID()

void QmitkSlicesInterpolator::SetCurrentContourListID ( )

protected

◆ SetDataStorage()

void QmitkSlicesInterpolator::SetDataStorage ( mitk::DataStorage::Pointer storage )

Sets the data storage used for interpolation feedback nodes.

◆ setEnabled

virtual void QmitkSlicesInterpolator::setEnabled ( bool )

virtualslot

◆ SignalRememberContourPositions

void QmitkSlicesInterpolator::SignalRememberContourPositions ( bool )

signal

◆ SignalShowMarkerNodes

void QmitkSlicesInterpolator::SignalShowMarkerNodes ( bool )

signal

◆ StartUpdateInterpolationTimer

void QmitkSlicesInterpolator::StartUpdateInterpolationTimer ( )

protectedslot

Starts the timer that periodically triggers interpolation updates.

◆ StopUpdateInterpolationTimer

void QmitkSlicesInterpolator::StopUpdateInterpolationTimer ( )

protectedslot

Stops the interpolation update timer.

◆ TranslateAndInterpolateChangedSlice() [1/2]

bool QmitkSlicesInterpolator::TranslateAndInterpolateChangedSlice	(	const itk::EventObject &	e,
		mitk::SliceNavigationController *	sliceNavigationController
	)

protected

Retrieves the currently selected PlaneGeometry from a SlicedGeometry3D that is generated by a SliceNavigationController and calls Interpolate to further process this PlaneGeometry into an interpolation.

Parameters

e	is a actually a mitk::SliceNavigationController::GeometrySliceEvent, sent by a SliceNavigationController
sliceNavigationController	the SliceNavigationController

◆ TranslateAndInterpolateChangedSlice() [2/2]

bool QmitkSlicesInterpolator::TranslateAndInterpolateChangedSlice ( const mitk::TimeGeometry * timeGeometry )

protected

◆ Uninitialize()

void QmitkSlicesInterpolator::Uninitialize ( )

Releases resources and disconnects from the tool manager and render windows.

◆ UpdateVisibleSuggestion()

void QmitkSlicesInterpolator::UpdateVisibleSuggestion ( )

protected

Called internally to update the interpolation suggestion. Finds out about the focused render window and requests an interpolation.

Member Data Documentation

◆ m_ActionToSlicerMap

ActionToSliceDimensionMapType QmitkSlicesInterpolator::m_ActionToSlicerMap

protected

Definition at line 225 of file QmitkSlicesInterpolator.h.

The documentation for this class was generated from the following file:

QmitkSlicesInterpolator.h

Public Slots

Signals

Public Member Functions

Protected Types

Protected Slots

Protected Member Functions

Protected Attributes

Detailed Description

Member Typedef Documentation

◆ ActionToSliceDimensionMapType

Constructor & Destructor Documentation

◆ QmitkSlicesInterpolator()

◆ ~QmitkSlicesInterpolator()

Member Function Documentation

◆ AcceptAllInterpolations()

◆ AcceptAllInterpolationsWithErrorHandling()

◆ ChangeSurfaceColor

◆ CreateActionToSlicer()

◆ Enable3DInterpolation

◆ EnableInterpolation

◆ FinishInterpolation

◆ GetDataStorage()

◆ Initialize()

◆ Interpolate()

◆ On2DInterpolationEnabled

◆ On3DInterpolationActivated

◆ On3DInterpolationEnabled

◆ OnAccept3DInterpolationClicked

◆ OnAcceptAllInterpolationsClicked

◆ OnAcceptAllPopupActivated

◆ OnAcceptInterpolationClicked

◆ OnInterpolationAborted()

◆ OnInterpolationActivated

◆ OnInterpolationDisabled

◆ OnInterpolationInfoChanged()

◆ OnInterpolationMethodChanged

◆ OnReinit3DInterpolation

◆ OnShowMarkers

◆ OnSliceChanged()

◆ OnSliceNavigationControllerDeleted()

◆ OnSurfaceInterpolationFinished

◆ OnSurfaceInterpolationInfoChanged()

◆ OnTimeChanged()

◆ OnToolManagerReferenceDataModified()

◆ OnToolManagerWorkingDataModified()

◆ Run3DInterpolation

◆ SetActiveLabelValue()

◆ SetCurrentContourListID()

◆ SetDataStorage()

◆ setEnabled

◆ SignalRememberContourPositions

◆ SignalShowMarkerNodes

◆ StartUpdateInterpolationTimer

◆ StopUpdateInterpolationTimer

◆ TranslateAndInterpolateChangedSlice() [1/2]

◆ TranslateAndInterpolateChangedSlice() [2/2]

◆ Uninitialize()

◆ UpdateVisibleSuggestion()

Member Data Documentation

◆ m_ActionToSlicerMap
