Collection of string constants used as property names for radiotherapy dose data nodes. More...
#include <mitkRTConstants.h>
Static Public Attributes | |
| static const std::string | DOSE_PROPERTY_NAME |
| static const std::string | PRESCRIBED_DOSE_PROPERTY_NAME |
| static const std::string | REFERENCE_DOSE_PROPERTY_NAME |
| static const std::string | REFERENCE_STRUCTURE_SET_PROPERTY_NAME |
| static const std::string | DOSE_TYPE_PROPERTY_NAME |
| static const std::string | REFERENCE_DESCRIPTION_DOSE_PROPERTY_NAME |
| static const std::string | DOSE_SUMMATION_TYPE_PROPERTY_NAME |
| static const std::string | DOSE_FRACTION_COUNT_PROPERTY_NAME |
| static const std::string | DOSE_FRACTION_NUMBER_OF_BEAMS_PROPERTY_NAME |
| static const std::string | DOSE_RADIATION_TYPE_PROPERTY_NAME |
| static const std::string | DOSE_SHOW_ISOLINES_PROPERTY_NAME |
| static const std::string | DOSE_SHOW_COLORWASH_PROPERTY_NAME |
| static const std::string | DOSE_ISO_LEVELS_PROPERTY_NAME |
| static const std::string | DOSE_FREE_ISO_VALUES_PROPERTY_NAME |
Detailed Description
Collection of string constants used as property names for radiotherapy dose data nodes.
This struct defines the standard property name strings used throughout the RT module to store and retrieve dose-related metadata on MITK DataNodes. These constants correspond to DICOM RT tags and visualization settings.
- See also
- mitk::DataNode
- mitk::RTUIConstants
Definition at line 33 of file mitkRTConstants.h.
Member Data Documentation
◆ DOSE_FRACTION_COUNT_PROPERTY_NAME
|
static |
Name of the property that encodes the number of fractions. It is for example in DICOM stored in tag (300A,0078) - Number of Fractions Prescribed (from the RTPLAN file if this file exists). This value could be used to further scale the dose according to dose summation type. For example a given plan consists of 8 fractions. Scaling the fraction dose by 8 gives the complete planned dose.
Definition at line 81 of file mitkRTConstants.h.
◆ DOSE_FRACTION_NUMBER_OF_BEAMS_PROPERTY_NAME
|
static |
Name of the property that encodes the number of beams. It is for example in DICOM stored in tag (300A,0080) - Number of Beams (from the RTPLAN file if this file exists).
Definition at line 87 of file mitkRTConstants.h.
◆ DOSE_FREE_ISO_VALUES_PROPERTY_NAME
|
static |
Name of the property that encodes user defined iso values that mark special dose values in the distribution.
Definition at line 112 of file mitkRTConstants.h.
◆ DOSE_ISO_LEVELS_PROPERTY_NAME
|
static |
Name of the property that encodes if the set of iso levels should be used to visualize the dose distribution.
Definition at line 107 of file mitkRTConstants.h.
◆ DOSE_PROPERTY_NAME
|
static |
Name of the property that indicates if a data/node is a dose.
Definition at line 39 of file mitkRTConstants.h.
◆ DOSE_RADIATION_TYPE_PROPERTY_NAME
|
static |
Name of the property that encodes the radiation type of beams. It is for example in DICOM stored in tag (300A,00C6) - Radiation Type (from the RTPLAN file if this file exists).
Definition at line 92 of file mitkRTConstants.h.
◆ DOSE_SHOW_COLORWASH_PROPERTY_NAME
|
static |
Name of the property that encodes if the color wash rendering should be activated for the node.
Definition at line 102 of file mitkRTConstants.h.
◆ DOSE_SHOW_ISOLINES_PROPERTY_NAME
|
static |
Name of the property that encodes if the iso line rendering should be activated for the node.
Definition at line 97 of file mitkRTConstants.h.
◆ DOSE_SUMMATION_TYPE_PROPERTY_NAME
|
static |
Name of the property that encodes the optional string property holding the information from the tag (3004,000A) - Dose Summation Type. This contains useful information for medical doctors
Definition at line 73 of file mitkRTConstants.h.
◆ DOSE_TYPE_PROPERTY_NAME
|
static |
Name of the property that encodes the optional string property holding the information from the tag (3004,0004) - Dose Type. This contains useful information for medical doctors
Definition at line 62 of file mitkRTConstants.h.
◆ PRESCRIBED_DOSE_PROPERTY_NAME
|
static |
Name of the property that encodes the prescribed dose associated with the data node If a RTPLAN file exists the value can be extracted from the tag (300A,0026) - Target Prescription Dose in the plan file.
Definition at line 45 of file mitkRTConstants.h.
◆ REFERENCE_DESCRIPTION_DOSE_PROPERTY_NAME
|
static |
Name of the property that encodes the optional string property holding the description information from the tag (300A,0016) - Dose Reference Description.
Definition at line 67 of file mitkRTConstants.h.
◆ REFERENCE_DOSE_PROPERTY_NAME
|
static |
Name of the property that encodes the reference dose that should be used for relative dose visualization/evaluation purpose. It is often the prescribed dose but may differ e.g. when to dose distributions should be compared using the same reference.
Definition at line 51 of file mitkRTConstants.h.
◆ REFERENCE_STRUCTURE_SET_PROPERTY_NAME
|
static |
Name of the property that encodes the reference structure set.
Definition at line 56 of file mitkRTConstants.h.
The documentation for this struct was generated from the following file:
