Property for storing a std::vector of values. More...

#include <mitkVectorProperty.h>

Inheritance diagram for mitk::VectorProperty< DATATYPE >:

Collaboration diagram for mitk::VectorProperty< DATATYPE >:

[legend]

Public Types
typedef std::vector< DATATYPE >	VectorType
	The type of the std::vector stored by this property. More...

typedef VectorProperty< DATATYPE >	Self

typedef BaseProperty	SuperClass

typedef itk::SmartPointer< Self >	Pointer

typedef itk::SmartPointer< const Self >	ConstPointer

Public Member Functions
std::vector< std::string >	GetClassHierarchy () const override

const char *	GetNameOfClass () const override

Pointer	Clone () const

std::string	GetValueAsString () const override
	Return the property value as a human-readable string. More...

virtual const VectorType &	GetValue () const
	Get a const reference to the contained vector. More...

virtual void	SetValue (const VectorType &parameter_vector)
	Set the content vector. More...

bool	ToJSON (nlohmann::json &j) const override
	Serialize the vector to JSON as a JSON array. More...

bool	FromJSON (const nlohmann::json &j) override
	Deserialize the vector from a JSON array. More...

Public Member Functions inherited from mitk::BaseProperty
	mitkClassMacroItkParent (BaseProperty, itk::Object)

Pointer	Clone () const

bool	operator== (const BaseProperty &property) const
	Compare two properties for equality. More...

BaseProperty &	operator= (const BaseProperty &property)
	Assign a property value to this instance. More...

bool	AssignProperty (const BaseProperty &property)
	Assign a property value to this instance and report success. More...

Static Public Member Functions
static const char *	GetStaticNameOfClass ()
	Return the static class name including the type-dependent prefix. More...

static Pointer	New ()

Protected Member Functions
	VectorProperty ()=default

	VectorProperty (const Self &other)

	mitkCloneMacro (Self)

Protected Member Functions inherited from mitk::BaseProperty
	BaseProperty ()

	BaseProperty (const BaseProperty &other)

	~BaseProperty () override

Additional Inherited Members
Static Public Attributes inherited from mitk::BaseProperty
static const std::string	VALUE_CANNOT_BE_CONVERTED_TO_STRING
	Default return value for properties that cannot be converted to a string. More...

Detailed Description

template<typename DATATYPE>
class mitk::VectorProperty< DATATYPE >

Property for storing a std::vector of values.

Templated over the data type of the std::vector that is held by this class. Setting and getting of std::vectors is implemented by-value.

The class manually expands most of mitkClassMacro to specifically override GetNameOfClass() and GetStaticNameOfClass() in order to return type-dependent class names (e.g., "DoubleVectorProperty", "IntVectorProperty"). This is essential for serialization.

Template Parameters

DATATYPE The element type of the stored vector.

See also: BaseProperty; VectorPropertyDataType

Definition at line 61 of file mitkVectorProperty.h.

Member Typedef Documentation

◆ ConstPointer

template<typename DATATYPE >

typedef itk::SmartPointer<const Self> mitk::VectorProperty< DATATYPE >::ConstPointer

Definition at line 74 of file mitkVectorProperty.h.

◆ Pointer

template<typename DATATYPE >

typedef itk::SmartPointer<Self> mitk::VectorProperty< DATATYPE >::Pointer

Definition at line 73 of file mitkVectorProperty.h.

◆ Self

template<typename DATATYPE >

typedef VectorProperty<DATATYPE> mitk::VectorProperty< DATATYPE >::Self

Definition at line 71 of file mitkVectorProperty.h.

◆ SuperClass

template<typename DATATYPE >

typedef BaseProperty mitk::VectorProperty< DATATYPE >::SuperClass

Definition at line 72 of file mitkVectorProperty.h.

◆ VectorType

template<typename DATATYPE >

typedef std::vector<DATATYPE> mitk::VectorProperty< DATATYPE >::VectorType

The type of the std::vector stored by this property.

Definition at line 65 of file mitkVectorProperty.h.

Constructor & Destructor Documentation

◆ VectorProperty() [1/2]

template<typename DATATYPE >

mitk::VectorProperty< DATATYPE >::VectorProperty ( )

protecteddefault

◆ VectorProperty() [2/2]

template<typename DATATYPE >

mitk::VectorProperty< DATATYPE >::VectorProperty ( const Self & other )

inlineprotected

Definition at line 137 of file mitkVectorProperty.h.

Member Function Documentation

◆ Clone()

template<typename DATATYPE >

Pointer mitk::VectorProperty< DATATYPE >::Clone ( ) const

◆ FromJSON()

template<typename DATATYPE >

bool mitk::VectorProperty< DATATYPE >::FromJSON ( const nlohmann::json & j )

overridevirtual

Deserialize the vector from a JSON array.

Parameters

[in] j The JSON array to read from.

Returns: Always true.

Implements mitk::BaseProperty.

◆ GetClassHierarchy()

template<typename DATATYPE >

std::vector<std::string> mitk::VectorProperty< DATATYPE >::GetClassHierarchy ( ) const

inlineoverride

Definition at line 75 of file mitkVectorProperty.h.

◆ GetNameOfClass()

template<typename DATATYPE >

const char* mitk::VectorProperty< DATATYPE >::GetNameOfClass ( ) const

inlineoverride

Definition at line 92 of file mitkVectorProperty.h.

◆ GetStaticNameOfClass()

template<typename DATATYPE >

static const char* mitk::VectorProperty< DATATYPE >::GetStaticNameOfClass ( )

inlinestatic

Return the static class name including the type-dependent prefix.

This function returns different strings depending on the template parameter, which is required for serialization to work correctly.

Returns: The class name string (e.g., "DoubleVectorProperty").

Definition at line 85 of file mitkVectorProperty.h.

◆ GetValue()

template<typename DATATYPE >

virtual const VectorType& mitk::VectorProperty< DATATYPE >::GetValue ( ) const

virtual

Get a const reference to the contained vector.

Returns: A const reference to the stored vector.

◆ GetValueAsString()

template<typename DATATYPE >

std::string mitk::VectorProperty< DATATYPE >::GetValueAsString ( ) const

overridevirtual

Return the property value as a human-readable string.

Since VectorProperty potentially holds many elements, only the first and last few elements appear in the string. Missing central elements are indicated by an ellipsis ("...").

Returns: A string representation showing the first and last elements.

Reimplemented from mitk::BaseProperty.

◆ mitkCloneMacro()

template<typename DATATYPE >

mitk::VectorProperty< DATATYPE >::mitkCloneMacro ( Self )

protected

◆ New()

template<typename DATATYPE >

static Pointer mitk::VectorProperty< DATATYPE >::New ( )

static

◆ SetValue()

template<typename DATATYPE >

virtual void mitk::VectorProperty< DATATYPE >::SetValue ( const VectorType & parameter_vector )

virtual

Set the content vector.

Parameters

[in] parameter_vector The new vector to store.

◆ ToJSON()

template<typename DATATYPE >

bool mitk::VectorProperty< DATATYPE >::ToJSON ( nlohmann::json & j ) const

overridevirtual

Serialize the vector to JSON as a JSON array.

Parameters

[out] j The JSON value to write into.

Returns: Always true.

Implements mitk::BaseProperty.

The documentation for this class was generated from the following file:

mitkVectorProperty.h
