MITK vector type extending itk::Vector with additional constructors and conversions. More...
#include <mitkVector.h>
Public Member Functions | |
| Vector () | |
| Default constructor. More... | |
| Vector (const mitk::Vector< TCoordRep, NVectorDimension > &r) | |
| Copy constructor. More... | |
| Vector< TCoordRep, NVectorDimension > & | operator= (const Vector< TCoordRep, NVectorDimension > &r) |
| Vector (const itk::Vector< TCoordRep, NVectorDimension > &r) | |
| Constructor to convert from itk::Vector to mitk::Vector. More... | |
| Vector (const TCoordRep r[NVectorDimension]) | |
| Constructor to convert an array to mitk::Vector. More... | |
| Vector (const TCoordRep &v) | |
| Vector (const vnl_vector< TCoordRep > &vnlVector) | |
| Constructor for vnl_vectors. More... | |
| Vector (const vnl_vector_fixed< TCoordRep, NVectorDimension > &vnlVectorFixed) | |
| Constructor for vnl_vector_fixed. More... | |
| template<typename... Args, typename = std::enable_if_t<(sizeof...(Args) == NVectorDimension)>> | |
| Vector (Args... args) | |
| template<typename ArrayType > | |
| void | FillVector (const ArrayType &array) |
| Copy elements from an array into this vector. More... | |
| template<typename ArrayType > | |
| void | ToArray (ArrayType array) const |
| Copy the values stored in this vector into an array. More... | |
| operator vnl_vector< TCoordRep > () const | |
| User-defined conversion of mitk::Vector to vnl_vector. More... | |
Detailed Description
template<class TCoordRep, unsigned int NVectorDimension = 3>
class mitk::Vector< TCoordRep, NVectorDimension >
MITK vector type extending itk::Vector with additional constructors and conversions.
Provides constructors from vnl_vector, vnl_vector_fixed, and variadic arguments, as well as conversion operators and utility methods for copying to/from array types.
- Template Parameters
-
TCoordRep Coordinate representation type (e.g. double, float). NVectorDimension Number of dimensions (default: 3).
Definition at line 38 of file mitkVector.h.
Constructor & Destructor Documentation
◆ Vector() [1/8]
|
inlineexplicit |
Default constructor.
Definition at line 42 of file mitkVector.h.
◆ Vector() [2/8]
|
inlineexplicit |
Copy constructor.
Definition at line 45 of file mitkVector.h.
◆ Vector() [3/8]
|
inline |
Constructor to convert from itk::Vector to mitk::Vector.
Definition at line 60 of file mitkVector.h.
◆ Vector() [4/8]
|
inline |
Constructor to convert an array to mitk::Vector.
- Parameters
-
[in] r The array.
- Attention
- Must have NVectorDimension valid arguments!
Definition at line 70 of file mitkVector.h.
◆ Vector() [5/8]
|
inline |
Constructor to initialize entire vector to one value.
Definition at line 78 of file mitkVector.h.
◆ Vector() [6/8]
|
inline |
Constructor for vnl_vectors.
- Exceptions
-
mitk::Exception If vnl_vector.size() != NVectorDimension.
Definition at line 83 of file mitkVector.h.
References mitkThrow.
◆ Vector() [7/8]
|
inline |
Constructor for vnl_vector_fixed.
Definition at line 99 of file mitkVector.h.
◆ Vector() [8/8]
|
inlineexplicit |
Definition at line 110 of file mitkVector.h.
Member Function Documentation
◆ FillVector()
|
inline |
Copy elements from an array into this vector.
Note that this method will assign doubles to floats without complaining!
- Parameters
-
[in] array The array whose values shall be copied. Must overload [] operator.
Definition at line 124 of file mitkVector.h.
◆ operator vnl_vector< TCoordRep >()
|
inline |
User-defined conversion of mitk::Vector to vnl_vector.
Note: the conversion to vnl_vector_fixed has not been implemented since this would collide with the conversion vnl_vector to vnl_vector_fixed provided by vnl.
Definition at line 148 of file mitkVector.h.
◆ operator=()
|
inline |
Pass-through assignment operator for the Vector base class.
Definition at line 51 of file mitkVector.h.
◆ ToArray()
|
inline |
Copy the values stored in this vector into an array.
- Parameters
-
[out] array The array which should store the values of this vector.
Definition at line 137 of file mitkVector.h.
The documentation for this class was generated from the following file:
