Coordinates a list of SliceNavigationControllers. More...
#include <mitkSlicesCoordinator.h>
Public Types | |
| typedef SlicesCoordinator | Self |
| typedef itk::Object | Superclass |
| typedef itk::SmartPointer< Self > | Pointer |
| typedef itk::SmartPointer< const Self > | ConstPointer |
| typedef std::vector< SliceNavigationController * > | SNCVector |
Public Member Functions | |
| virtual std::vector< std::string > | GetClassHierarchy () const |
| virtual const char * | GetClassName () const |
| void | AddSliceController (SliceNavigationController *snc) |
| void | RemoveSliceController (SliceNavigationController *snc) |
| virtual void | SetLinkPlanes (bool _arg) |
| virtual bool | GetLinkPlanes () |
| virtual void | LinkPlanesOn () |
| virtual void | LinkPlanesOff () |
| void | ResetMouseCursor () |
| Resets the mouse cursor (if modified by the SlicesCoordinator) to its original state. More... | |
Static Public Member Functions | |
| static const char * | GetStaticNameOfClass () |
| static Pointer | New () |
Protected Member Functions | |
| SlicesCoordinator () | |
| Default Constructor. More... | |
| ~SlicesCoordinator () override | |
| void | SetMouseCursor (const char *xpm[], int hotspotX, int hotspotY) |
| Sets the specified mouse cursor. More... | |
| virtual void | OnSliceControllerAdded (SliceNavigationController *snc) |
| virtual void | OnSliceControllerRemoved (SliceNavigationController *snc) |
Protected Attributes | |
| SNCVector | m_SliceNavigationControllers |
| bool | m_LinkPlanes |
| bool | m_MouseCursorSet |
Detailed Description
Coordinates a list of SliceNavigationControllers.
Each SliceNavigationController can select one slice from a TimeGeometry. This class (SlicesCoordinator) coordinates several SliceNavigationControllers to facilitate e.g. rotation of slices. A new class is needed, because for rotation one has to know an axis of rotation. Such an axis is most easily determined from the "other slices", which are not known by a SliceNavigationController.
Definition at line 41 of file mitkSlicesCoordinator.h.
Member Typedef Documentation
◆ ConstPointer
| typedef itk::SmartPointer<const Self> mitk::SlicesCoordinator::ConstPointer |
Definition at line 44 of file mitkSlicesCoordinator.h.
◆ Pointer
Definition at line 44 of file mitkSlicesCoordinator.h.
◆ Self
Definition at line 44 of file mitkSlicesCoordinator.h.
◆ SNCVector
| typedef std::vector<SliceNavigationController *> mitk::SlicesCoordinator::SNCVector |
Definition at line 45 of file mitkSlicesCoordinator.h.
◆ Superclass
| typedef itk::Object mitk::SlicesCoordinator::Superclass |
Definition at line 44 of file mitkSlicesCoordinator.h.
Constructor & Destructor Documentation
◆ SlicesCoordinator()
|
protected |
Default Constructor.
Definition at line 19 of file mitkSlicesCoordinator.cpp.
◆ ~SlicesCoordinator()
|
overrideprotected |
clear list of controllers
Definition at line 20 of file mitkSlicesCoordinator.cpp.
Member Function Documentation
◆ AddSliceController()
| void mitk::SlicesCoordinator::AddSliceController | ( | SliceNavigationController * | snc | ) |
Add to list of managed slices. Check if CreatedWorldGeometry of SNC is managable (i.e. there is basically only one planegeometry)
Definition at line 21 of file mitkSlicesCoordinator.cpp.
References m_SliceNavigationControllers, and OnSliceControllerAdded().
◆ GetClassHierarchy()
|
inlinevirtual |
Definition at line 44 of file mitkSlicesCoordinator.h.
◆ GetClassName()
|
virtual |
◆ GetLinkPlanes()
|
virtual |
◆ GetStaticNameOfClass()
|
inlinestatic |
Definition at line 44 of file mitkSlicesCoordinator.h.
◆ LinkPlanesOff()
|
virtual |
◆ LinkPlanesOn()
|
virtual |
◆ New()
|
static |
◆ OnSliceControllerAdded()
|
protectedvirtual |
for implementation in subclasses
Definition at line 72 of file mitkSlicesCoordinator.cpp.
Referenced by AddSliceController().
◆ OnSliceControllerRemoved()
|
protectedvirtual |
for implementation in subclasses
Definition at line 77 of file mitkSlicesCoordinator.cpp.
Referenced by RemoveSliceController().
◆ RemoveSliceController()
| void mitk::SlicesCoordinator::RemoveSliceController | ( | SliceNavigationController * | snc | ) |
Remove one controller from the internal list
Definition at line 31 of file mitkSlicesCoordinator.cpp.
References m_SliceNavigationControllers, and OnSliceControllerRemoved().
◆ ResetMouseCursor()
| void mitk::SlicesCoordinator::ResetMouseCursor | ( | ) |
Resets the mouse cursor (if modified by the SlicesCoordinator) to its original state.
Should be used by subclasses and from external application instead of using QmitkApplicationCursor directly to avoid conflicts.
Definition at line 51 of file mitkSlicesCoordinator.cpp.
References mitk::ApplicationCursor::GetInstance(), m_MouseCursorSet, and mitk::ApplicationCursor::PopCursor().
◆ SetLinkPlanes()
|
virtual |
Set/Get whether planes should stay linked to each other (by fixing their relative angle)
◆ SetMouseCursor()
|
protected |
Sets the specified mouse cursor.
Use this in subclasses instead of using QmitkApplicationCursor directly.
Definition at line 60 of file mitkSlicesCoordinator.cpp.
References mitk::ApplicationCursor::GetInstance(), m_MouseCursorSet, mitk::ApplicationCursor::PopCursor(), and mitk::ApplicationCursor::PushCursor().
Member Data Documentation
◆ m_LinkPlanes
|
protected |
Definition at line 92 of file mitkSlicesCoordinator.h.
◆ m_MouseCursorSet
|
protected |
Definition at line 94 of file mitkSlicesCoordinator.h.
Referenced by ResetMouseCursor(), and SetMouseCursor().
◆ m_SliceNavigationControllers
|
protected |
Definition at line 90 of file mitkSlicesCoordinator.h.
Referenced by AddSliceController(), and RemoveSliceController().
The documentation for this class was generated from the following files:
