#include <mitkSceneReaderV1.h>
Public Member Functions | |
| mitkClassMacro (SceneReaderV1, SceneReader) | |
| Pointer | Clone () const |
| bool | LoadScene (TiXmlDocument &document, const std::string &workingDirectory, DataStorage *storage) override |
 Public Member Functions inherited from mitk::SceneReader | |
| mitkClassMacroItkParent (SceneReader, itk::Object) | |
| Pointer | Clone () const |
Static Public Member Functions | |
| static Pointer | New () |
| Static Public Member Functions inherited from mitk::SceneReader | |
| static Pointer | New () |
Protected Types | |
| typedef std::pair< DataNode::Pointer, std::list< std::string > > | NodesAndParentsPair |
| typedef std::list< NodesAndParentsPair > | OrderedNodesList |
| typedef std::map< std::string, DataNode * > | IDToNodeMappingType |
| typedef std::map< DataNode *, std::string > | NodeToIDMappingType |
Protected Member Functions | |
| DataNode::Pointer | LoadBaseDataFromDataTag (TiXmlElement *dataElement, const std::string &workingDirectory, bool &error) |
| tries to create one DataNode from a given XML <node> element More... | |
| bool | DecorateNodeWithProperties (DataNode *node, TiXmlElement *nodeElement, const std::string &workingDirectory) |
| reads all the properties from the XML document and recreates them in node More... | |
| void | ClearNodePropertyListWithExceptions (DataNode &node, PropertyList &propertyList) |
| Clear a default property list and handle some exceptions. More... | |
| bool | DecorateBaseDataWithProperties (BaseData::Pointer data, TiXmlElement *baseDataNodeElem, const std::string &workingDir) |
| reads all properties assigned to a base data element and assigns the list to the base data object More... | |
Protected Attributes | |
| OrderedNodesList | m_OrderedNodePairs |
| IDToNodeMappingType | m_NodeForID |
| NodeToIDMappingType | m_IDForNode |
| UIDGenerator | m_UIDGen |
Detailed Description
Definition at line 17 of file mitkSceneReaderV1.h.
Member Typedef Documentation
◆ IDToNodeMappingType
|
protected |
Definition at line 65 of file mitkSceneReaderV1.h.
◆ NodesAndParentsPair
|
protected |
Definition at line 63 of file mitkSceneReaderV1.h.
◆ NodeToIDMappingType
|
protected |
Definition at line 66 of file mitkSceneReaderV1.h.
◆ OrderedNodesList
|
protected |
Definition at line 64 of file mitkSceneReaderV1.h.
Member Function Documentation
◆ ClearNodePropertyListWithExceptions()
|
protected |
Clear a default property list and handle some exceptions.
Called after assigning a BaseData object to a fresh DataNode via SetData(). This call to SetData() would create default properties that have not been there when saving the scene. Since they can produce problems, we clear the list and use only those properties that we read from the scene file.
This method also handles some exceptions for backwards compatibility. Those exceptions are documented directly in the code of the method.
Definition at line 284 of file mitkSceneReaderV1.cpp.
References mitk::PropertyList::Clear(), mitk::PropertyList::ConcatenatePropertyList(), mitk::DataNode::GetData(), mitk::PropertyList::GetProperty(), and mitk::PropertyList::New().
Referenced by DecorateNodeWithProperties().
◆ Clone()
| Pointer mitk::SceneReaderV1::Clone | ( | ) | const |
◆ DecorateBaseDataWithProperties()
|
protected |
reads all properties assigned to a base data element and assigns the list to the base data object
The baseDataNodeElem is supposed to be the <properties file="..."> element.
Definition at line 377 of file mitkSceneReaderV1.cpp.
References MITK_ERROR, and mitk::PropertyListDeserializer::New().
Referenced by LoadScene().
◆ DecorateNodeWithProperties()
|
protected |
reads all the properties from the XML document and recreates them in node
Definition at line 333 of file mitkSceneReaderV1.cpp.
References ClearNodePropertyListWithExceptions(), mitk::DataNode::GetPropertyList(), MITK_ERROR, and mitk::PropertyListDeserializer::New().
Referenced by LoadScene().
◆ LoadBaseDataFromDataTag()
|
protected |
tries to create one DataNode from a given XML <node> element
Definition at line 240 of file mitkSceneReaderV1.cpp.
References mitk::IOUtil::Load(), MITK_ERROR, MITK_WARN, and mitk::DataNode::New().
Referenced by LoadScene().
◆ LoadScene()
|
overridevirtual |
Reimplemented from mitk::SceneReader.
Definition at line 52 of file mitkSceneReaderV1.cpp.
References mitk::DataStorage::Add(), mitk::ProgressBar::AddStepsToDo(), DecorateBaseDataWithProperties(), DecorateNodeWithProperties(), mitk::DataStorage::Exists(), mitk::ProgressBar::GetInstance(), LoadBaseDataFromDataTag(), m_IDForNode, m_NodeForID, m_OrderedNodePairs, MITK_ERROR, MITK_WARN, and mitk::ProgressBar::Progress().
◆ mitkClassMacro()
| mitk::SceneReaderV1::mitkClassMacro | ( | SceneReaderV1 | , |
| SceneReader | |||
| ) |
◆ New()
|
static |
Member Data Documentation
◆ m_IDForNode
|
protected |
Definition at line 70 of file mitkSceneReaderV1.h.
Referenced by LoadScene().
◆ m_NodeForID
|
protected |
Definition at line 69 of file mitkSceneReaderV1.h.
Referenced by LoadScene().
◆ m_OrderedNodePairs
|
protected |
Definition at line 68 of file mitkSceneReaderV1.h.
Referenced by LoadScene().
◆ m_UIDGen
|
protected |
Definition at line 72 of file mitkSceneReaderV1.h.
The documentation for this class was generated from the following files:
