Predicate that evaluates if the given DataNode's data object has the same geometry (in terms of spacing, origin, orientation) like the reference geometry. One can either check the whole time geometry of the date node by defining a referenc time geometry or check against one given reference base geometry. If the predicate should check against a base geometry, you can specify the timepoint of the data's time geometry that should be checked. If no timepoint is defined the predicate will evaluate the data geometry in the first timestep. Evaluates to "false" for unsupported or undefined data objects/geometries. More...

#include <mitkNodePredicateGeometry.h>

Inheritance diagram for mitk::NodePredicateGeometry:

[legend]

Collaboration diagram for mitk::NodePredicateGeometry:

[legend]

Public Types
typedef NodePredicateGeometry	Self

typedef NodePredicateBase	Superclass

typedef itk::SmartPointer< Self >	Pointer

typedef itk::SmartPointer< const Self >	ConstPointer

Public Types inherited from mitk::NodePredicateBase
typedef NodePredicateBase	Self

typedef itk::Object	Superclass

typedef itk::SmartPointer< Self >	Pointer

typedef itk::SmartPointer< const Self >	ConstPointer

Public Member Functions
virtual std::vector< std::string >	GetClassHierarchy () const override

virtual const char *	GetClassName () const

virtual void	SetCheckPrecision (mitk::ScalarType _arg)

virtual mitk::ScalarType	GetCheckPrecision ()

	~NodePredicateGeometry () override

bool	CheckNode (const mitk::DataNode *node) const override
	This method will be used to evaluate the node. Has to be overwritten in subclasses. More...

Public Member Functions inherited from mitk::NodePredicateBase
	~NodePredicateBase () override
	Standard Destructor. More...

Static Public Member Functions
static const char *	GetStaticNameOfClass ()

static Pointer	New (const TimeGeometry *_arg)

static Pointer	New (const BaseGeometry *_arg)

static Pointer	New (const BaseGeometry *_arga, TimePointType _argb)

Static Public Member Functions inherited from mitk::NodePredicateBase
static const char *	GetStaticNameOfClass ()

Protected Member Functions
	NodePredicateGeometry (const BaseGeometry *refGeometry)

	NodePredicateGeometry (const BaseGeometry *refGeometry, TimePointType relevantTimePoint)

	NodePredicateGeometry (const TimeGeometry *refGeometry)

Protected Attributes
BaseGeometry::ConstPointer	m_RefGeometry

TimeGeometry::ConstPointer	m_RefTimeGeometry

TimePointType	m_TimePoint

bool	m_UseTimePoint

mitk::ScalarType	m_CheckPrecision

Detailed Description

Predicate that evaluates if the given DataNode's data object has the same geometry (in terms of spacing, origin, orientation) like the reference geometry. One can either check the whole time geometry of the date node by defining a referenc time geometry or check against one given reference base geometry. If the predicate should check against a base geometry, you can specify the timepoint of the data's time geometry that should be checked. If no timepoint is defined the predicate will evaluate the data geometry in the first timestep. Evaluates to "false" for unsupported or undefined data objects/geometries.

Documentation

Definition at line 35 of file mitkNodePredicateGeometry.h.
