mitk::VtkRepresentationProperty Class Reference

#include <mitkVtkRepresentationProperty.h>

Inheritance diagram for mitk::VtkRepresentationProperty:

Collaboration diagram for mitk::VtkRepresentationProperty:

Public Types
typedef VtkRepresentationProperty	Self
typedef EnumerationProperty	Superclass
typedef itk::SmartPointer< Self >	Pointer
typedef itk::SmartPointer< const Self >	ConstPointer
Public Types inherited from mitk::EnumerationProperty
typedef EnumerationProperty	Self
typedef BaseProperty	Superclass
typedef itk::SmartPointer< Self >	Pointer
typedef itk::SmartPointer< const Self >	ConstPointer
typedef unsigned int	IdType
typedef std::map< IdType, std::string >	EnumIdsContainerType
typedef std::map< std::string, IdType >	EnumStringsContainerType
typedef EnumIdsContainerType::const_iterator	EnumConstIterator
Public Types inherited from mitk::BaseProperty
typedef BaseProperty	Self
typedef itk::Object	Superclass
typedef itk::SmartPointer< Self >	Pointer
typedef itk::SmartPointer< const Self >	ConstPointer

Public Member Functions
virtual std::vector< std::string >	GetClassHierarchy () const override
virtual const char *	GetClassName () const
Pointer	Clone () const
virtual int	GetVtkRepresentation ()
virtual void	SetRepresentationToPoints ()
virtual void	SetRepresentationToWireframe ()
virtual void	SetRepresentationToSurface ()
Public Member Functions inherited from mitk::EnumerationProperty
Pointer	Clone () const
virtual bool	SetValue (const std::string &name)
virtual bool	SetValue (const IdType &id)
virtual IdType	GetValueAsId () const
std::string	GetValueAsString () const override
virtual void	Clear ()
virtual EnumIdsContainerType::size_type	Size () const
virtual EnumConstIterator	Begin () const
virtual EnumConstIterator	End () const
virtual std::string	GetEnumString (const IdType &id) const
virtual IdType	GetEnumId (const std::string &name) const
virtual bool	IsValidEnumerationValue (const IdType &id) const
virtual bool	IsValidEnumerationValue (const std::string &name) const
const EnumIdsContainerType &	GetEnumIds () const
const EnumStringsContainerType &	GetEnumStrings () const
EnumIdsContainerType &	GetEnumIds ()
EnumStringsContainerType &	GetEnumStrings ()
EnumerationProperty &	operator= (const EnumerationProperty &)=delete
Public Member Functions inherited from mitk::BaseProperty
Pointer	Clone () const
bool	operator== (const BaseProperty &property) const
	Subclasses must implement IsEqual(const BaseProperty&) to support comparison. More...
BaseProperty &	operator= (const BaseProperty &property)
	Assigns property to this BaseProperty instance. More...
bool	AssignProperty (const BaseProperty &property)
	Assigns property to this BaseProperty instance. More...

Static Public Member Functions
static const char *	GetStaticNameOfClass ()
static Pointer	New ()
static Pointer	New (const IdType &_arg)
static Pointer	New (const std::string &_arg)
Static Public Member Functions inherited from mitk::EnumerationProperty
static const char *	GetStaticNameOfClass ()
static Pointer	New ()
Static Public Member Functions inherited from mitk::BaseProperty
static const char *	GetStaticNameOfClass ()

Protected Member Functions
	VtkRepresentationProperty ()
	VtkRepresentationProperty (const IdType &value)
	VtkRepresentationProperty (const std::string &value)
bool	AddEnum (const std::string &name, const IdType &id) override
virtual void	AddRepresentationTypes ()
Protected Member Functions inherited from mitk::EnumerationProperty
	EnumerationProperty ()
	EnumerationProperty (const EnumerationProperty &)
bool	IsEqual (const BaseProperty &property) const override
bool	Assign (const BaseProperty &property) override
Protected Member Functions inherited from mitk::BaseProperty
	BaseProperty ()
	BaseProperty (const BaseProperty &other)
	~BaseProperty () override

Additional Inherited Members
Static Public Attributes inherited from mitk::BaseProperty
static const std::string	VALUE_CANNOT_BE_CONVERTED_TO_STRING
	Default return value if a property which can not be returned as string. More...

Detailed Description

Encapsulates the enumeration vtkRepresentation. Valid values are (VTK constant/Id/string representation): VTK_POINTS/0/Points, VTK_WIREFRAME/1/Wireframe, VTK_SURFACE/2/Surface Default is the Surface representation

Definition at line 31 of file mitkVtkRepresentationProperty.h.

Member Typedef Documentation

ConstPointer

typedef itk::SmartPointer<const Self> mitk::VtkRepresentationProperty::ConstPointer

Definition at line 34 of file mitkVtkRepresentationProperty.h.

Pointer

typedef itk::SmartPointer<Self> mitk::VtkRepresentationProperty::Pointer

Definition at line 34 of file mitkVtkRepresentationProperty.h.

Self

typedef VtkRepresentationProperty mitk::VtkRepresentationProperty::Self

Definition at line 34 of file mitkVtkRepresentationProperty.h.

Superclass

typedef EnumerationProperty mitk::VtkRepresentationProperty::Superclass

Definition at line 34 of file mitkVtkRepresentationProperty.h.

Constructor & Destructor Documentation

VtkRepresentationProperty() [1/3]

mitk::VtkRepresentationProperty::VtkRepresentationProperty ( )

protected

Constructor. Sets the representation to a default value of Surface(2)

Definition at line 16 of file mitkVtkRepresentationProperty.cpp.

References AddRepresentationTypes(), and mitk::EnumerationProperty::SetValue().

VtkRepresentationProperty() [2/3]

mitk::VtkRepresentationProperty::VtkRepresentationProperty ( const IdType &  value )

protected

Constructor. Sets the representation to the given value. If it is not valid, the representation is set to Surface(2)

Parameters

value

the integer representation of the representation

Definition at line 22 of file mitkVtkRepresentationProperty.cpp.

References AddRepresentationTypes(), mitk::EnumerationProperty::IsValidEnumerationValue(), and mitk::EnumerationProperty::SetValue().

VtkRepresentationProperty() [3/3]

mitk::VtkRepresentationProperty::VtkRepresentationProperty ( const std::string &  value )

protected

Constructor. Sets the representation to the given value. If it is not valid, the representation is set to Surface(2)

Parameters

value

the string representation of the representation

Definition at line 35 of file mitkVtkRepresentationProperty.cpp.

References AddRepresentationTypes(), mitk::EnumerationProperty::IsValidEnumerationValue(), and mitk::EnumerationProperty::SetValue().

Member Function Documentation

AddEnum()

bool mitk::VtkRepresentationProperty::AddEnum ( const std::string &  name, const IdType &  id  )

overrideprotectedvirtual

this function is overridden as protected, so that the user may not add additional invalid representation types.

Reimplemented from mitk::EnumerationProperty.

Definition at line 75 of file mitkVtkRepresentationProperty.cpp.

References mitk::EnumerationProperty::AddEnum().

Referenced by AddRepresentationTypes().

AddRepresentationTypes()

void mitk::VtkRepresentationProperty::AddRepresentationTypes ( )

protectedvirtual

Adds the enumeration types as defined by vtk to the list of known enumeration values.

Definition at line 68 of file mitkVtkRepresentationProperty.cpp.

References AddEnum().

Referenced by VtkRepresentationProperty().

Clone()

Pointer mitk::VtkRepresentationProperty::Clone

(

)

const

GetClassHierarchy()

virtual std::vector<std::string> mitk::VtkRepresentationProperty::GetClassHierarchy ( ) const

inlineoverridevirtual

Reimplemented from mitk::EnumerationProperty.

Definition at line 34 of file mitkVtkRepresentationProperty.h.

GetClassName()

virtual const char* mitk::VtkRepresentationProperty::GetClassName ( ) const

virtual

Reimplemented from mitk::EnumerationProperty.

GetStaticNameOfClass()

static const char* mitk::VtkRepresentationProperty::GetStaticNameOfClass ( )

inlinestatic

Definition at line 34 of file mitkVtkRepresentationProperty.h.

GetVtkRepresentation()

int mitk::VtkRepresentationProperty::GetVtkRepresentation ( )

virtual

Returns the current representation value as defined by VTK constants.

Returns

the current representation as VTK constant.

Definition at line 48 of file mitkVtkRepresentationProperty.cpp.

References mitk::EnumerationProperty::GetValueAsId().

Referenced by mitk::PlaneGeometryDataVtkMapper3D::GenerateDataForRenderer().

New() [1/3]

static Pointer mitk::VtkRepresentationProperty::New ( )

static

Referenced by mitkEnumerationPropertyTest(), mitkPropertySerializationTest(), QmitkSlicesInterpolator::QmitkSlicesInterpolator(), QmitkSurfaceBasedInterpolatorWidget::QmitkSurfaceBasedInterpolatorWidget(), and mitk::SurfaceVtkMapper3D::SetDefaultPropertiesForVtkProperty().

New() [2/3]

static Pointer mitk::VtkRepresentationProperty::New ( const IdType &  _arg )

inlinestatic

Definition at line 40 of file mitkVtkRepresentationProperty.h.

New() [3/3]

static Pointer mitk::VtkRepresentationProperty::New ( const std::string &  _arg )

inlinestatic

Definition at line 42 of file mitkVtkRepresentationProperty.h.

SetRepresentationToPoints()

void mitk::VtkRepresentationProperty::SetRepresentationToPoints ( )

virtual

Sets the representation type to VTK_POINTS.

Definition at line 53 of file mitkVtkRepresentationProperty.cpp.

References mitk::EnumerationProperty::SetValue().

SetRepresentationToSurface()

void mitk::VtkRepresentationProperty::SetRepresentationToSurface ( )

virtual

Sets the representation type to VTK_SURFACE.

Definition at line 63 of file mitkVtkRepresentationProperty.cpp.

References mitk::EnumerationProperty::SetValue().

SetRepresentationToWireframe()

void mitk::VtkRepresentationProperty::SetRepresentationToWireframe ( )

virtual

Sets the representation type to VTK_WIREFRAME.

Definition at line 58 of file mitkVtkRepresentationProperty.cpp.

References mitk::EnumerationProperty::SetValue().

Referenced by mitk::ShowSegmentationAsSmoothedSurface::ThreadedUpdateSuccessful(), and mitk::ShowSegmentationAsSurface::ThreadedUpdateSuccessful().

---

The documentation for this class was generated from the following files:

• mitkVtkRepresentationProperty.h
• mitkVtkRepresentationProperty.cpp
