#include <mitkMovieGeneratorOpenCV.h>
Public Member Functions | |
| mitkClassMacro (MovieGeneratorOpenCV, MovieGenerator) | |
| Pointer | Clone () const |
| void | SetFileName (const char *fileName) override |
| filename under which movie is saved More... | |
| void | SetFourCCCodec (char *codec) |
| void | SetFrameRate (unsigned int rate) override |
| void | SetRemoveColouredFrame (bool) |
 Public Member Functions inherited from mitk::MovieGenerator | |
| mitkClassMacroItkParent (MovieGenerator, itk::LightObject) | |
| virtual void | SetStepper (Stepper *stepper) |
| stepper used to control movie generation More... | |
| virtual void | SetRenderer (BaseRenderer *renderer) |
| renderer to record More... | |
| virtual bool | WriteMovie () |
| uses given stepper and filename to create a movie from the active OpenGL context More... | |
| virtual bool | WriteCurrentFrameToMovie () |
| alternative way, which does not use a stepper; More... | |
| virtual void | ReleaseMovieWriter () |
| releases a movie writer after usage of WriteCurrentFrameToMovie() More... | |
| unsigned int | GetFrameRate () |
Static Public Member Functions | |
| static Pointer | New () |
| Static Public Member Functions inherited from mitk::MovieGenerator | |
| static Pointer | New (void) |
Protected Member Functions | |
| MovieGeneratorOpenCV () | |
| bool | InitGenerator () override |
| called directly before the first frame is added More... | |
| bool | AddFrame (void *data) override |
| used to add a frame More... | |
| bool | TerminateGenerator () override |
| called after the last frame is added More... | |
| Protected Member Functions inherited from mitk::MovieGenerator | |
| MovieGenerator () | |
| default constructor More... | |
Protected Attributes | |
| std::string | m_sFile |
| name of output file More... | |
| int | m_dwRate |
| frame rate More... | |
| Protected Attributes inherited from mitk::MovieGenerator | |
| char | m_fileName [1024] |
| stores the movie filename More... | |
| Stepper * | m_stepper |
| stores the used stepper More... | |
| BaseRenderer * | m_renderer |
| stores the uses renderer More... | |
| int | m_width |
| InitGenerator() stores movie size in those variables. More... | |
| int | m_height |
| bool | m_initialized |
| unsigned int | m_FrameRate |
Detailed Description
Definition at line 29 of file mitkMovieGeneratorOpenCV.h.
Constructor & Destructor Documentation
◆ MovieGeneratorOpenCV()
|
protected |
Definition at line 19 of file mitkMovieGeneratorOpenCV.cpp.
References m_dwRate, and mitk::MovieGenerator::m_initialized.
Member Function Documentation
◆ AddFrame()
|
overrideprotectedvirtual |
used to add a frame
Implements mitk::MovieGenerator.
Definition at line 115 of file mitkMovieGeneratorOpenCV.cpp.
References mitk::MovieGenerator::m_height, and mitk::MovieGenerator::m_width.
◆ Clone()
| Pointer mitk::MovieGeneratorOpenCV::Clone | ( | ) | const |
◆ InitGenerator()
|
overrideprotectedvirtual |
called directly before the first frame is added
Implements mitk::MovieGenerator.
Definition at line 46 of file mitkMovieGeneratorOpenCV.cpp.
References mitk::BaseRenderer::GetRenderWindow(), m_dwRate, mitk::MovieGenerator::m_height, mitk::MovieGenerator::m_renderer, m_sFile, and mitk::MovieGenerator::m_width.
◆ mitkClassMacro()
| mitk::MovieGeneratorOpenCV::mitkClassMacro | ( | MovieGeneratorOpenCV | , |
| MovieGenerator | |||
| ) |
◆ New()
|
static |
◆ SetFileName()
|
overridevirtual |
filename under which movie is saved
Reimplemented from mitk::MovieGenerator.
Definition at line 30 of file mitkMovieGeneratorOpenCV.cpp.
References m_sFile.
◆ SetFourCCCodec()
|
inline |
Definition at line 40 of file mitkMovieGeneratorOpenCV.h.
◆ SetFrameRate()
|
overridevirtual |
Reimplemented from mitk::MovieGenerator.
Definition at line 36 of file mitkMovieGeneratorOpenCV.cpp.
References m_dwRate.
◆ SetRemoveColouredFrame()
| void mitk::MovieGeneratorOpenCV::SetRemoveColouredFrame | ( | bool | RemoveColouredFrame | ) |
if true the movie will be cutted by a 10 pixel margin in order to remove the standard mitk coloured borders default: true
Definition at line 41 of file mitkMovieGeneratorOpenCV.cpp.
◆ TerminateGenerator()
|
overrideprotectedvirtual |
called after the last frame is added
Implements mitk::MovieGenerator.
Definition at line 124 of file mitkMovieGeneratorOpenCV.cpp.
Member Data Documentation
◆ m_dwRate
|
protected |
frame rate
Definition at line 70 of file mitkMovieGeneratorOpenCV.h.
Referenced by InitGenerator(), MovieGeneratorOpenCV(), and SetFrameRate().
◆ m_sFile
|
protected |
name of output file
Definition at line 67 of file mitkMovieGeneratorOpenCV.h.
Referenced by InitGenerator(), and SetFileName().
The documentation for this class was generated from the following files:
