mitk::GridVolumeMapperProperty Class Reference

#include <mitkGridVolumeMapperProperty.h>

Inheritance diagram for mitk::GridVolumeMapperProperty:

Collaboration diagram for mitk::GridVolumeMapperProperty:

Public Types
enum	MapperType { RAYCAST, PT, ZSWEEP }
Public Types inherited from mitk::EnumerationProperty
typedef EnumerationProperty	Self
typedef BaseProperty	Superclass
typedef itk::SmartPointer< Self >	Pointer
typedef itk::SmartPointer< const Self >	ConstPointer
typedef unsigned int	IdType
typedef std::map< IdType, std::string >	EnumIdsContainerType
typedef std::map< std::string, IdType >	EnumStringsContainerType
typedef EnumIdsContainerType::const_iterator	EnumConstIterator
Public Types inherited from mitk::BaseProperty
typedef BaseProperty	Self
typedef itk::Object	Superclass
typedef itk::SmartPointer< Self >	Pointer
typedef itk::SmartPointer< const Self >	ConstPointer

Public Member Functions
	mitkClassMacro (GridVolumeMapperProperty, EnumerationProperty)
Pointer	Clone () const
	mitkNewMacro1Param (GridVolumeMapperProperty, const IdType &)
	mitkNewMacro1Param (GridVolumeMapperProperty, const std::string &)
virtual void	SetVolumeMapperToPT ()
virtual void	SetVolumeMapperToZSweep ()
virtual void	SetVolumeMapperToRayCast ()
Public Member Functions inherited from mitk::EnumerationProperty
virtual std::vector< std::string >	GetClassHierarchy () const override
virtual const char *	GetClassName () const
Pointer	Clone () const
virtual bool	SetValue (const std::string &name)
virtual bool	SetValue (const IdType &id)
virtual IdType	GetValueAsId () const
std::string	GetValueAsString () const override
virtual void	Clear ()
virtual EnumIdsContainerType::size_type	Size () const
virtual EnumConstIterator	Begin () const
virtual EnumConstIterator	End () const
virtual std::string	GetEnumString (const IdType &id) const
virtual IdType	GetEnumId (const std::string &name) const
virtual bool	IsValidEnumerationValue (const IdType &id) const
virtual bool	IsValidEnumerationValue (const std::string &name) const
const EnumIdsContainerType &	GetEnumIds () const
const EnumStringsContainerType &	GetEnumStrings () const
EnumIdsContainerType &	GetEnumIds ()
EnumStringsContainerType &	GetEnumStrings ()
EnumerationProperty &	operator= (const EnumerationProperty &)=delete
Public Member Functions inherited from mitk::BaseProperty
Pointer	Clone () const
bool	operator== (const BaseProperty &property) const
	Subclasses must implement IsEqual(const BaseProperty&) to support comparison. More...
BaseProperty &	operator= (const BaseProperty &property)
	Assigns property to this BaseProperty instance. More...
bool	AssignProperty (const BaseProperty &property)
	Assigns property to this BaseProperty instance. More...

Static Public Member Functions
static Pointer	New ()
Static Public Member Functions inherited from mitk::EnumerationProperty
static const char *	GetStaticNameOfClass ()
static Pointer	New ()
Static Public Member Functions inherited from mitk::BaseProperty
static const char *	GetStaticNameOfClass ()

Protected Member Functions
	GridVolumeMapperProperty ()
	GridVolumeMapperProperty (const IdType &value)
	GridVolumeMapperProperty (const std::string &value)
bool	AddEnum (const std::string &name, const IdType &id) override
virtual void	AddRepresentationTypes ()
Protected Member Functions inherited from mitk::EnumerationProperty
	EnumerationProperty ()
	EnumerationProperty (const EnumerationProperty &)
bool	IsEqual (const BaseProperty &property) const override
bool	Assign (const BaseProperty &property) override
Protected Member Functions inherited from mitk::BaseProperty
	BaseProperty ()
	BaseProperty (const BaseProperty &other)
	~BaseProperty () override

Additional Inherited Members
Static Public Attributes inherited from mitk::BaseProperty
static const std::string	VALUE_CANNOT_BE_CONVERTED_TO_STRING
	Default return value if a property which can not be returned as string. More...

Detailed Description

Extends the enumeration prop mitkEnumerationPropery. Adds the value (constant/Id/string representation): PT/0/Projected Tetrahedra, ZSWEEP/1/ZSweep, RAYCAST/2/Ray Cast Default is the Wireframe representation

Definition at line 27 of file mitkGridVolumeMapperProperty.h.

Member Enumeration Documentation

MapperType

enum mitk::GridVolumeMapperProperty::MapperType

Enumerator
RAYCAST
PT
ZSWEEP

Definition at line 30 of file mitkGridVolumeMapperProperty.h.

Constructor & Destructor Documentation

GridVolumeMapperProperty() [1/3]

mitk::GridVolumeMapperProperty::GridVolumeMapperProperty ( )

protected

Constructor. Sets the representation to a default value of Wireframe(1)

Definition at line 16 of file mitkGridVolumeMapperProperty.cpp.

References AddRepresentationTypes(), PT, and mitk::EnumerationProperty::SetValue().

GridVolumeMapperProperty() [2/3]

mitk::GridVolumeMapperProperty::GridVolumeMapperProperty ( const IdType &  value )

protected

Constructor. Sets the representation to the given value. If it is not valid, the representation is set to Wireframe(1)

Parameters

value

the integer representation of the representation

Definition at line 22 of file mitkGridVolumeMapperProperty.cpp.

References AddRepresentationTypes(), mitk::EnumerationProperty::IsValidEnumerationValue(), PT, and mitk::EnumerationProperty::SetValue().

GridVolumeMapperProperty() [3/3]

mitk::GridVolumeMapperProperty::GridVolumeMapperProperty ( const std::string &  value )

protected

Constructor. Sets the representation to the given value. If it is not valid, the representation is set to Wireframe(1)

Parameters

value

the string representation of the representation

Definition at line 35 of file mitkGridVolumeMapperProperty.cpp.

References AddRepresentationTypes(), mitk::EnumerationProperty::IsValidEnumerationValue(), PT, and mitk::EnumerationProperty::SetValue().

Member Function Documentation

AddEnum()

bool mitk::GridVolumeMapperProperty::AddEnum ( const std::string &  name, const IdType &  id  )

overrideprotectedvirtual

this function is overridden as protected, so that the user may not add additional invalid representation types.

Reimplemented from mitk::EnumerationProperty.

Definition at line 70 of file mitkGridVolumeMapperProperty.cpp.

Referenced by AddRepresentationTypes().

AddRepresentationTypes()

void mitk::GridVolumeMapperProperty::AddRepresentationTypes ( )

protectedvirtual

Adds the enumeration types as defined by vtk to the list of known enumeration values.

Definition at line 63 of file mitkGridVolumeMapperProperty.cpp.

References AddEnum(), PT, RAYCAST, and ZSWEEP.

Referenced by GridVolumeMapperProperty().

Clone()

Pointer mitk::GridVolumeMapperProperty::Clone

(

)

const

mitkClassMacro()

mitk::GridVolumeMapperProperty::mitkClassMacro	(	GridVolumeMapperProperty	,
		EnumerationProperty
	)

mitkNewMacro1Param() [1/2]

mitk::GridVolumeMapperProperty::mitkNewMacro1Param	(	GridVolumeMapperProperty	,
		const IdType &
	)

mitkNewMacro1Param() [2/2]

mitk::GridVolumeMapperProperty::mitkNewMacro1Param	(	GridVolumeMapperProperty	,
		const std::string &
	)

New()

static Pointer mitk::GridVolumeMapperProperty::New ( )

static

Referenced by mitk::UnstructuredGridVtkMapper3D::SetDefaultProperties().

SetVolumeMapperToPT()

void mitk::GridVolumeMapperProperty::SetVolumeMapperToPT ( )

virtual

Sets the mapper to projected tetrahedra.

Definition at line 48 of file mitkGridVolumeMapperProperty.cpp.

References PT, and mitk::EnumerationProperty::SetValue().

SetVolumeMapperToRayCast()

void mitk::GridVolumeMapperProperty::SetVolumeMapperToRayCast ( )

virtual

Sets the mapper to ray casting.

Definition at line 58 of file mitkGridVolumeMapperProperty.cpp.

References RAYCAST, and mitk::EnumerationProperty::SetValue().

SetVolumeMapperToZSweep()

void mitk::GridVolumeMapperProperty::SetVolumeMapperToZSweep ( )

virtual

Sets the mapper to zsweep.

Definition at line 53 of file mitkGridVolumeMapperProperty.cpp.

References mitk::EnumerationProperty::SetValue(), and ZSWEEP.

---

The documentation for this class was generated from the following files:

• mitkGridVolumeMapperProperty.h
• mitkGridVolumeMapperProperty.cpp
